Our Products - Vertical washing machine for insulating glass VEGA

WASH

Vertical washing machine for insulating glass VEGA

Our vertical washing station consists of a painted steel inlet conveyor, a stainless steel washing machine that integrates both washing and drying, and an outlet conveyor also made of painted steel. However, our machines can be customized according to our customers’ needs.

Full description

Technical Data

Technical Characteristics

Gallery

Video

Full description

Technical Data

Technical Characteristics

Gallery

Video

HEIGHT	H1600 – H2000 – H2500 – H3210
N. BRUSHES	4 o 6
MIN. THICKNESS. GLASS	3 mm
MAX THICKNESS. GLASS	12 mm , 20 mm , 50 mm
SPEED	Variable from 2 to 12mt/min
WORK PLAN.	Standard 600 mm (+/- 50mm) , Variable upon request

HEIGHT	A	B	C	D	E	F	G	H
H1600	8400	2380	2670	600	1980	2500	2950	2950
H2000	8400	2380	3070	600	1980	2500	2950	2950
H2500	8400	2380	3570	600	1980	2500	2950	2950
H3210	10600	2580	4280	600	1980	3800	5000	1800
