Key Strengths:
| Daily production: | Approximately 300 glass panels per day. |
| Available heights: | H1600 mm , H2000 mm, H2500 mm |
| Minimum glass dimensions: | L400 mm x H200 mm |
| Maximum glass dimensions: | L3000 mm x H2500 mm (lengths can be increased upon request) |
| Minimum glass thickness: | 3 mm |
| Maximum glass thickness: | 60 mm |
| Gas injection system: | Yes (it can also be built without gas injection system upon request) |
| Double/Triple glazing production: | Yes (refer to single machine specifications sheet for details) |
| Shaped glass | Yes (refer to single machine specifications sheet for details) |
| Structural Glass | Yes (refer to single machine specifications sheet for details) |
| Maximum Load: | 120Kg mt/linear |
| HEIGHT | A | B | C | D | E | F | G |
| H1600 | 24000 | 1350 | 1600 | 650 | 6500 | 9000 | 8500 |
| H2000 | 24000 | 1350 | 2000 | 650 | 6500 | 9000 | 8500 |
| H2500 | 24000 | 1350 | 2500 | 650 | 6500 | 9000 | 8500 |
