| Minimum Glass Size: | L380 mm x H180 mm |
| Maximum Glass Dimensions: | L2850 mm x H2500 mm |
| Glass Thicknesses: | 12 mm – 50 mm |
| Transport Speed: | from 2 to 25 mt/min |
| Overall Dimensions: | L7600 mm x 1395 mm x H3300 mm |
| Structure: | Painted steel |
| Pressing System: | Roller-based |
| Roller Assembly: | Automatic for Double and Triple Glass Panels |
| Pressing Monitoring: | Controlled via PLC through Operator Panel |
| Sensors: | N°4 |
| Power Supply: | 20 Kw |
| Voltage: | 400 V – 50Hz3Ph + Ground+ Neutral |
| Weight: | 600 kg |
| Glass Transport Height: | 650 mm (+/- 50mm) |
| HEIGHT | A | B | C | D | E | F | G | H |
| H1600 | 7600 | 1395 | 2590 | 600 | 980 | 700 | 3950 | 2950 |
| H2000 | 7600 | 1395 | 2990 | 600 | 980 | 700 | 3950 | 2950 |
| H2500 | 7600 | 1395 | 3490 | 600 | 980 | 700 | 3950 | 2950 |
